EZVIZ Mini Trooper

Detail
Specs

Mini Trooper

Mini Trooper

Wires Gone. Secure Any Angle.

The Mini Trooper HD security camera has absolutely no wires so it looks sleeker and can help you secure any angle. Weatherproof and rugged, it provides maximum performance year round, both indoors and outdoors.
- High Dynamic Algorithm
  Video Technology
- Battery Life Up
  To 9 Months*
- Weatherproof for
  Outdoor Operation
- Completely Wire-Free
  with Wi-Fi Setup
- Audio Recording
- Night Vision
- Motion Alerts
- Local Storage up to
  128GB with MicroSD Card
* Mini Trooper's battery life can last up to 9 months when using the four included CR123A batteries based on up to 30, ten-second motion triggered event recordings per day.
Wire-Free

Remember that area your wired camera couldn't reach? Not a problem, anymore. Now you can secure almost any angle, indoors or outdoors, with the Wire-Free/Battery Operated Mini Trooper.

Unrivaled HD Video and Visual Quality

EZVIZ has a legacy of Unrivaled HD Quality. Our patent pending High Dynamic Algorithm (HDα) video delivers clear resolution unlike any other HD camera on the market. The Mini Trooper provides the sharpest imagery, all day long.

Mini Trooper

Leading Competitor
- Predictive Encoding

  Delivers superior video quality by prioritizing moving objects in forefront with high resolution detail using spatial-domain and time-based smart digitization.
- Digital Video
  Noise Suppression

  Guarantees video quality of moving objects by minimizing background noise to provide optimal viewing performance.
- Extended Bitrate
  Modulation

  Intelligent analysis of resource requirements at different times of day to dynamically adjust bitrate to ensure high video quality of moving objects.
Battery life up to 9 months*
Rest Assured, Knowing It’s All Secure.

You never have to worry if your home is safe. Long Battery Life plus
the Low Battery Indicator in the EZVIZ App provide total peace of
mind to ensure you never miss a moment, even when you’re away.

* Mini Trooper's battery life can last up to 9 months when using the four included CR123A batteries based on up to 30, ten-second motion triggered event recordings per day.

View Anytime, Anywhere with the EZVIZ App

Each Mini Trooper Base Station supports up to 6 cameras. With our Unified Mobile App, you can view and manage all EZVIZ devices – wired, wireless and wire-free – from the palm of your hand.
Easily View, Store & Secure
The Base Station stores
video and photos securely
up to 128GB with a
MicroSD card.

Multilayer security and
end-to-end video encryption
keep video safe.

Easily access live view,
video and photos anytime
with the EZVIZ App.
View Quick Start Guide

How to Setup the Mini Trooper

Please update firmware to the latest version for best experience.
- Connect to
  Router
- Sync up to
  6 Camera(s)
- Download
  EZVIZ App
- Watch from
  Anywhere
Videos to help you setup your Mini Trooper

CLICK TO PLAY CLICK TO PLAY

Multiple Storage Options

With multiple storage options, you can choose where to save your recordings. The cameras can even save to all three locations at the same time for added backup in case a camera is damaged or your network crashes.

MicroSD Card

Encrypted Cloud Storage

EZVIZ NVR

Security at Your Fingertips

With EZVIZ app or EZVIZ Studio, you can protect, capture, save and share what's valuable to you.

Live View

Real-Time Talk

Instant Alerts

Video History

Up to 8x Zoom

Smart Home Enabled

*EZVIZ app interface images are for illustrative purposes only.

Mini Trooper

Wire-Free Battery Powered

Model parameters	Model	CS-CV316
Model parameters	Model	HD Wire-Free Indoor/Outdoor Camera
Camera	Image sensor	1/4”Progressive Scan CMOS
	Minimum Illumination	0.02Lux @(F2.0,AGC ON), 0 Lux with IR
	Shutter	1/30s to 1/100,000s
	Lens	2.0mm @ F2.4
	Lens	Horizontal View Angle: 101°,Diagonal View Angle: 116°
	Lens Mount	M12
	Day & Night	IR Cut Filter
	IR Range	Up to 25 feet (7.5m)
	Audio	Built-in Microphone
Compression	Video Compression	H.264 Main Profile
	Video Bit Rate	Adaptive bit rate
	Audio Bit Rate	Adaptive bit rate
Image	Max. Resolution	1280*720
Image	Frame Rate	Up to 15fps (1280*720), Adaptive
Network	Smart Alarm	Smart Motion Detection
Network	One-key configuration	Sync with Base Station
Wireless parameters	Standard	IEEE802.11b, 802.11g, 802.11n
	Frequency Range	2.4 GHz to 2.4835 GHz
	Channel Bandwidth	Supports 20MHz
	Security	64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
	Transmission Rate	802.11b: 11Mbps, 802.11g: 54Mbps, 802.11n: 150Mbps
General	Operating Conditions	14 °F to 131 °F (-10°C ~ 55°C), Humidity 95% or less (non-condensing)
	Power Consumption	6 VDC±10% , Max. 2W
	Battery	Camera holds up to four CR123A batteries; Up to 9 month battery life varies based on settings, usage and temperature
	Weatherproof	IP65
	Dimensions (inch)	2.782.522.41" (70.5mm64mm61.3mm)
	Weight	0.26 lb (121 g), battery not included

Model parameters	Model	CS-W2S-A1
Audio and Video Input	Cloud Cameras	Supports up to 6 Mini Trooper cameras
Storage Parameters	Capacity	Supports up to 128GB microSD card, 8GB microSD card included
Wi-Fi Parameters	Frequency Bandwidth	Dual Band, 2.4G/5G
Wi-Fi Parameters	Range	Camera range is up to 300 ft (100 m)*
Network	Ethernet Port	1 WAN port
General	Operating Conditions	32 °F to 104 °F (0°C ~ 40°C), Humidity 5% ~ 90%(non-condensing)
	Power Consumption	Max. 10W
	Dimensions	6.033.082.56" inch (1537865mm)
	Weight	0.61 lbs (284g)
